Pelvis form
Rectangular
Universal utility
Pant/uni utility/legger
Pant legger
Pelvis/topper
| Technical Features | SPLINTER MANUAL |
| Steam pressure | 5 BAR (requested) |
| Operating air pressure | 6 BAR (requested) |
| Average steam consumption | 15-20 kg/h - 5 BAR |
| Vacuum outlet | 100 mm |
| Steam entrance connection | 3/8” |
| Steam exhaust connection | 3/8” |
| Overall dimensions | 120x140x160 H cm |
| Weight | 200-300 kg (according to model)) |
| Packing | 2,8 m3 |
| Standard Voltage | 230 V - 50 Hz |
| Upon request | 400 V+N - 50 Hz (only with steam boiler)) |
ACCESSORIES AVAILABLE BY REQUEST
- Built-in 24 l. boiler (10-12-15 KW)
- Head closing by pedal + safety frame
- Stainless steel arm
- Steam iron assembly with iron and iron rest
- Polished top head
- Blowing motor kit
- 1,5 HP compressor
- Steam/air gun kit
- Vacuum motor
