INDUSTRIAL series Washer-extractors are suitable for hospitals, community, labour camps, army, prisons, hotels, restaurants, textile industry as well as individual washing-dyeing industry and any other facility with relevant volumes of garments and linen to wash. The INDUSTRIAL series Washer-extractors are used to wash cotton, wool, synthetic fibers and any other kind of fabric.



Features:

  • Programmable computer control system with user friendly design, multiple languages and large LCD screen (Button panel or touch panel can be chosen by the user), with washing programs clearly showing and easy to use. Manual control system is available as well
  • Patent design of the bearing sealing technology which supports the drum made of AISI304 stainless steel and of the high strength outer cylinder. The new high-strength bearingseat, with oversized bearing and high-accuracy short axle, ensure that machine’s lifespan is prolonged also during overload situation
  • The added weight at the front of the suspended element, is counterbalanced from the shock-absorber system combined by springs and bearings, so to reach the perfect balancing of the suspended object. The effective vibration-reducing rate can reach 98% to 100%,no special foundation or fixing system needed for the machine installation
  • The variable frequency drive (VFD) with LS inverters and high-quality TIMKEN bearings enable quiet operation. The main shaft sealing material, the stainless steel panel and the unique material of the soap supply system are effective against high temperatures and strong acids. The door locking device ensures safety, while the larger diameter loading door and intuitive design allow for easy loading and unloading, thus reducing labor powerdesign allow for easy loading and

UV sterilization

Multilingual computer touch

Predisposition for connection of external dispensers

Quality bearings

Possibility of installing a built-in coin acceptor

TEHNICAL PARAMETERS

ModelUnitCBH 12/CD 12CBH 16/CD 16CBH 22/CD 22
WASHER
Load capacitykg121622
Basket volumelt116148194
Basket dimensionsmmØ 635×365Ø 635×465Ø 740×450
Washing speedrpm323232
Average speedrpm420420420
Spin speedmm10001000900
G factorG363363343
Motor powerkW1.852.23
HeatingkW2×43×44×4
InverterkW2.22.23.7
Electrical connection400V – III + N + T400V – III + N + T400V – III + N + T
Heating typeTopla voda/strujaTopla voda/strujaTopla voda/struja
Water inlet diameterDN3/4″3/4″3/4″
Drain diameterInch3”3”3”
DRYER
Load capacitykg121622
Basket volumelt229286379
Basket dimensionsmmØ 745×525Ø 745×655Ø 855×660
Basket motor powerkW0.250.250.55
Fan motorkW0.370.370.75
Electric heatingkW10.510.513.5
Electrical connectionTip400V – III + N + T400V – III + N + T400V – III + N + T
GAS consumptionkg/h0.60.81
CFMBTU/h55,00075,00095,000
Air flowm3/h8008001,000
GAS inletInch1/21/21/2
Smoke outletmm190190190
Dimensionsmm805 x 1,054 x 2,190804 x 1,184 x 2,190905 x 1,190 x 2,400
Net weightkg442508634
Packing dimensionsmm955 x 1,204 x 2,340955 x 1,334 x 2,3401,055 x 1,340 x 2,550
Gross weightkg482548674
